The machine is designed for the filling of liquid and paste-like products in pre-formed plastic cups and containers of various shapes with sealing of pre-cut aluminum foil lids and capping with a plastic lid. Double row two-carousel machine is small in size with high productivity for one machine-man.
Output with product:
Electromechanical drive – up to 7200 cups/hour
Servo drive – up to 8000 cups/hour
Weight: 1600 kg
Power supply: 380V, 50 Hz
Power consumption: 2 kW
Air-pressure: 0.6 MPa
Сompressed air consumption: no more 700-800 liters/min
Connection to CIP
Cleanup system
Automatic feeding of cups
Rotary table for final assembly (1200 mm)
High productivity
Compactness
Vacuum-compensator (to prevent swelling of aluminium lids)
High quality sealing of pre-cut aluminium lids (tubular coiled heating element)
